The INTUPAK SPA22 addresses the simple yet decisive question of how to power wall-mounted devices. With a plethora of wall-mounted preamplifiers, amplifiers and wireless receiver panels in the market, most manufacturers count on the installers’ ability to hide a wall wart in a drywall or run a long low-voltage cable from a remote location. Intusonic however delivers the smarter answer in the shape of a sleek and flexible PSU, fitting just into wall box sizes with minimal depth (86 mm) offering flush or surface mount options like other Intusonic wall-mounted products. With its symmetrical +-12V low-noise DC output, it provides the groundwork for great, high-headroom audio quality. And with terminal strip outputs plus IntuLink in-line RJ45 connections with data throughput and power refresh, it can power both stand-alone preamp products like the VAA22 or provide long-distance power beyond a zoner's on-board supply abilities to IntuGrid wall panels.
Flush-mount PSU for the INTUPAK VAA22 mixing panel
- Flush mounting
- For further information about this product, please refer to the Data Sheet under "Downloads"
Scope of delivery
- 1 x device
- 1 x user manual
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 3 W |
| Protection class: | Protection class I |
| Power connection: | Mains input via screw terminal |
| Network connection: | RJ-45 (F) mounting version |
| Housing color: | Black matte |
| Housing design: | Flush mounting |
| Dimensions: | Width: 8.6 cm Depth: 5.8 cm Height: 8.6 cm |
| Weight: | 0.24 kg |
